ADF Linea 100 Duo Double sided Insert Wood Heater

From $6,520.00

Pricing for Fireplace Box only. FLUE KIT and ACCESSORIES are sold separately.



Linea 100 Duo is all about contemporary lines and a strong sense of style. Expertly constructed by some of the world’s finest craftsman, ADF incorporates their heritage and time-honored tradition into every design. The Linea 100 Duo provides a considerable 17kW of heat output. Exhibiting all the traits that come with every ADF fire, these elegant fires combine a simplistic linear design with a 5mm steel firebox lined with high density firebricks. This automatically insulates the combustion chamber to allow for a superior heat reflection. Duel doors swing open for convenient reloading and showcase the stunning flames, and lively embers all whilst providing an enchanting ambiance. Acquiring an ADF wood burning fireplace isn’t simply ensuring a heating solution for your home; it is comfort, dependability, well-being and a work of art. Optional Extras: Flat edge frame 30mm, Profile Frame 30mm, duel fan kit, zero clearance box.



Brochure



Installation Manual



Specs
SKU: ADH100ID Categories: , Tags: , ,
Description

Heat output: 17kW (200-250m2)
Dimensions: W1012mm x H465mm x D550mm
Efficiency: 63%
Emissions: 1.2g/kg
Construction: 5mm steel with Vermiculite lining.

Optional Extras: Dual built-in fan, Zero Clearance box
Flue Size: 8″ active.

Made in Portugal
